Organic AntifreezeNature's non-toxic alternatives

Crops and animals contain natural antifreeze compounds, some of which are utilised in heat transfer fluids. The most commonly used organic antifreeze is Glycerine, also referred to as Glycerol, which is easily derived from soya, rapeseed and cattle. Ethanol and Methanol, produced organically, both have antifreeze characteristics, but are flammable at concentrations above 3%.

More recently Betaine, derived from sugar-beet and Bio-PG, derived from corn, have become available, but supplies are limited and subsequently expensive. Efficiency wise, blending several organic products together often improves their individual performance and resistance to biological contamination, which is reflected in the formulations for CoolFlow ECO2, Thermox FXC2 etc.

Other Antifreeze drums
Other Antifreeze drums

Organic based products

Coolflow ECO2 Coolflow ECO2

B BCBAA

Ecologically and Environmentally Friendly Non Toxic Antifreeze and Secondary Refrigerant for process cooling & AC systems. Based on Refined Vegetable Extracts and ASTM D1384 proven Corrosion, Scale and Biological Inhibitors.

Show more...

  • Summary - Rating: BSuitable for systems where low environmental impact and ecological sustainability is preferred. Average efficiency but lower in cost compared with MPG based fluids.

  • Efficiency - Rating: CAverage thermal conductivity and high viscosity at sub-zero temperatures, results in reduced heat transfer efficiency and increased energy demands when compared with DTX, IGE and LVF.

  • Antifreeze - Rating: BProvides protection down to -50°C but more volume is required to achieve the same freeze-point protection compared with DTX, IGE and LVF.

  • Corrosion Control - Rating: ALong-Life formulation with synergistic corrosion inhibitors to exceed BS6580 and ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for food & beverage processing systems and where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.26 g/cm³

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is slightly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of Coolflow ECO2 %

Refractive Index

-10

25.0

1.355

-15

32.0

1.362

-20

38.0

1.367

-25

43.0

1.372

-30

48.0

1.377

-35

52.0

1.380

Request

Show less

Coolflow ECO3 Coolflow ECO3

B BCBAA

Ecologically and Environmentally Friendly Non Toxic Antifreeze and Secondary Refrigerant for process cooling & AC systems. Based on Bio-PG and ASTM D1384 proven Corrosion, Scale and Biological Inhibitors.

Show more...

  • Summary - Rating: BSuitable for systems where low environmental impact and ecological sustainability is preferred. Slightly more efficient than ECO2 but more expensive per litre.

  • Efficiency - Rating: CLow Thermal Conductivity and high Viscosity at sub-zero temperatures, results in reduced heat transfer efficiency and increased energy demands.

  • Antifreeze - Rating: BProvides protection down to -50°C but more volume is required to achieve the same freeze-point protection compared with DTX, IGE and LVF.

  • Corrosion Control - Rating: ALong-Life formulation with synergistic corrosion inhibitors to exceed BS6580 and ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for food & beverage processing systems and where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.26 g/cm³

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is slightly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of Coolflow ECO3 %

Refractive Index

-10

25.0

1.363

-15

32.0

1.372

-20

38.0

1.378

-25

43.0

1.384

-30

48.0

1.389

-35

52.0

1.394

Request

Show less

Thermox FXC2 Thermox FXC2

B BCBAA

Ecologically and Environmentally Friendly non-toxic geothermal heat transfer fluid with antifreeze function, for use in geothermal, GSHP & air-source heat recovery systems. Based on refined vegetable extracts and ASTM D1384 proven corrosion, scale and biological inhibitors.

Show more...

  • Summary - Rating: BSuitable for geothermal, GSHP and air-source systems where low environmental impact and ecological sustainability is preferred. Average efficiency but lower in cost compared with MPG based fluids.

  • Efficiency - Rating: CAverage thermal conductivity and high viscosity at sub-zero temperatures, results in lower heat transfer efficiency and increased energy demands when compared with DTX and ITF.

  • Antifreeze - Rating: BProvides protection down to -50°C but more volume is required to achieve the same freeze-point protection compared with DTX and ITF.

  • Corrosion Control - Rating: ALong-Life formulation with synergistic corrosion inhibitors to exceed BS6580 and ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for systems where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.26 g/cm³

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is slightly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of Thermox FXC2 %

Refractive Index

-10

25.0

1.355

-15

32.0

1.362

-20

38.0

1.367

-25

43.0

1.372

-30

48.0

1.377

-35

52.0

1.380

Request

Show less

Thermaflow VT3 Thermaflow VT3

B BCBAA

Ecologically and Environmentally Friendly Non Toxic Heat Transfer Fluid with Antifreeze for use in Hot Water Heating Systems. Based on Refined Vegetable Extracts and ASTM D1384 high temperature rated Corrosion, Scale and Biological Inhibitors.

Show more...

  • Summary - Rating: BSuitable for central heating and LTHW systems where low environmental impact and ecological sustainability is preferred. Average efficiency but lower in cost compared with MPG based fluids.

  • Efficiency - Rating: CAverage thermal conductivity and high viscosity at sub-zero temperatures, results in lower heat transfer efficiency and increased energy demands when compared with Thermaflow DTX and CMF.

  • Antifreeze - Rating: BProvides protection down to -50°C but more volume is required to achieve the same freeze-point protection compared with Thermaflow DTX and CMF.

  • Corrosion Control - Rating: ALong-Life high temperature rated formulation with synergistic corrosion inhibitors to exceed ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for systems where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.26 g/cm³

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is slightly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of Thermaflow VT3 %

Refractive Index

-10

25.0

1.355

-15

32.0

1.362

-20

38.0

1.367

-25

43.0

1.372

-30

48.0

1.377

-35

52.0

1.380

Request

Show less

Biotherm VB4 Biotherm VB4

B BCBAA

Ecologically and Environmentally Friendly Non Toxic Heat Transfer Fluid with Antifreeze. Based on Refined Vegetable Extracts and ASTM D1384 proven Corrosion, Scale and Biological Inhibitors, for use in Biomass Heating Systems.

Show more...

  • Summary - Rating: BSuitable for biomass boiler heating systems where low environmental impact and ecological sustainability is preferred. Average efficiency but lower in cost compared with MPG based fluids.

  • Efficiency - Rating: CAverage thermal conductivity and high viscosity at sub-zero temperatures, results in lower heat transfer efficiency and increased energy demands when compared with Biotherm DTX and BE2.

  • Antifreeze - Rating: BProvides protection down to -50°C but more volume is required to achieve the same freeze-point protection compared with Biotherm DTX and BE2.

  • Corrosion Control - Rating: ALong-Life high temperature rated formulation with synergistic corrosion inhibitors to exceed ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for systems where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.26 g/cm³

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is slightly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of Biotherm VB4 %

Refractive Index

-10

25.0

1.355

-15

32.0

1.362

-20

38.0

1.367

-25

43.0

1.372

-30

48.0

1.377

-35

52.0

1.380

Request

Show less
